InteliMains 210 Global Guide
261
Setpoint group Scheduler Related FW 2.0.0
Range [units] Including / Skip / Postpone [-]
Default value Including Alternative config NO
Step [-]
Comm object 0 Related applications MCB, MGCB, BTB
Description
Behavior of Timer 2 Function (page 257) on weekends.
Including
Timer 2 Function (page 257) counter is running on the weekends and Timer 2 Function
(page 257) can be active.
Skip
Timer 2 Function (page 257) counter is running on the weekends but Timer 2 Function
(page 257) isn’t active.
Postpone
Timer 2 Function (page 257) counter isn’t running on the weekends and Timer 2 Function
(page 257) isn’t active. If the activation of timer is counted on the weekend, than timer will
be activated after weekend. Another activation of timer is counted from original date of
first occurrence date.
Timer 2 Weekends
6 back to List of setpoints
Setpoint group Scheduler Related FW 2.0.0
Range [units] Monday / Tuesday / Wednesday / Thursday / Friday / Saturday/ Sunday[-]
Default value All OFF Alternative config NO
Step [-]
Comm object 0 Related applications MCB, MGCB, BTB
Description
Use this setpoint to include or exclude individual days of week. To select the day use Up and Down buttons.
To change the value of day use Enter button.
Timer 2 Day
6 back to List of setpoints
Setpoint group Scheduler Related FW 2.0.0
Range [units] Repeated Day / Repeated Day In Week [-]
Default value Repeated Day Alternative config NO
Step [-]
Comm object 0 Related applications MCB, MGCB, BTB
Description
Use this setpoint to adjust behavior of monthly repetition of the Timer 2 Function (page 257).
Repeated Day
Chose one day in month when Timer 2 Function (page 257) will be activated.
Repeated Day In Week
Chose days in one week when Timer 2 Function (page 257) will be activated.
Timer 2 Repeat Day
6 back to List of setpoints
