InteliMains 210 Global Guide
298
Corner-Grounded Delta
Split Phase Delta
Three phase voltage measurement L1,L2,L3 with 120° phase shift
No neutral is available 3x CT (Current Transformer)
High Leg D High Leg Delta connection
Three phase voltage measurement L1,L2,L3
3x CT (Current Transformer)
3Ph4Wire Grounded Star (Grounded Wye) connection – 3PY
Three phase voltage measurement L1,L2,L3 with 120° phase shift
3x CT (Current Transformer)
Note: This value is used when binary input ALTERNATE CONFIG 2 (PAGE 401) is active.
6 back to List of setpoints
Subgroup: Configuration 3
Setpoint group Basic settings Related FW 2.0.0
Range [units] 45 .. 65 [Hz]
Default value 50 Hz Alternative config YES
Step 1 Hz
Comm object 15197 Related applications MCB, MGCB, BTB
Description
Nominal system frequency (usually 50 or 60 Hz).
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 401) is active.
Nominal Frequency 3
6 back to List of setpoints
Setpoint group Basic settings Related FW 2.0.0
Range [units] 80 .. 20 000 [V]
Default value 231 V Alternative config YES
Step 1 V
Comm object 12054 Related applications MCB, MGCB, BTB
Description
Nominal system voltage (phase to neutral).
Note: This value is used when binary input ALTERNATE CONFIG 3 (PAGE 401) is active.
Nominal Voltage Ph-N 3
6 back to List of setpoints
