Controller Address (page 181) has to be set to the same value as in the PC tool.
IP Address Mode (page 289) can be set to AUTOMATIC when there is DHCP service is available. Otherwise
it needs to be set to FIXED.
IP Address (page 290) is either set automatically or it can be adjusted to a specific requested value.
Subnet Mask (page 290) is either set automatically or it can be adjusted to a specific requested.
Gateway IP (page 290) can be set here when it is used.
ComAp TCP Port (page 294) number is 23. Make sure that this port is open for communication in your
network.
Connection using InteliConfig
Image 5.7 First screen of InteliConfig - select connect to controller
