Components & Controls
33
C3M2-OM-EN-02
Warning
Risk of crushing! Only touch the lever at the grip, do not reach back under
the lever.
D. Backrest Angle Adjustment
To set the angle of the backrest the operator must sit on the seat with their back
touching lightly against the backrest.
To adjust the angle of the backrest pull up the locking lever (D) to release the
backrest catch. Do not press back against the backrest when releasing the
backrest catch.
Lean forward or back at the waist to adjust the angle of the backrest. Release
the locking lever when the backrest is at the desired angle.
It should not be possible to move the backrest after it has been locked. Lean
back and forward on the seat to ensure it is locked in position.
E. Seatbelt
To fasten the seatbelt:
Sit back in the operator’s seat.
Pull the seatbelt out of its retractor and place it across the lap.
The belt must not be twisted.
Place the seatbelt tongue into the buckle.
To release the seatbelt press the red button on the buckle.
F. Horizontal Adjustment
The seat can be moved forward or back as required by the operator. Only touch the
horizontal adjustment lever at the grip provided.
Pull lever F up to release the horizontal adjustment catch.
Slide the seat forward or back to the desired position.
Release lever F to lock the seat in position.
After the adjustment, the locking lever must latch into the desired position. It
should not be possible to move the seat when it is locked.
G. Backrest Extension
The backrest extension is not adjustable.
H. Lumbar Support Adjustment
The lumbar support adjustment knob H allows the support on the lower backrest to be
adjusted to suit the individual operator. There are five setting positions.
Turn knob H clockwise to increase the lumbar support.
Turn knob H anticlockwise to reduce the lumbar support.
