C4-C5XL MK3 O&S
3-7
C4000MK3-OM-EN-11
De Stacking
Approach stack with mast retracted and in
vertical position.
Stop at face of stack, select neutral and apply
parking brake.
Elevate forks to permit entry into pallet.
Extend mast and enter the pallet with the forks.
Elevate load until clear of stack and tilt mast backwards to stabilise load.
Operate accelerator pedal to ensure that the engine speed is sufficient to
prevent stalling.
Retract mast fully and lower load to 150mm (6”) above ground, or where
possible on to the platforms
Double Forking a Load
If it is not possible to engage forks fully when lifting a load it will be necessary
to move the load closer to the front of the machine before lifting.
To Double Fork a Load:
Raise the load slightly and retract the mast sufficiently to bring the load
closer to the machine.
Lower the load ensuring that it is still properly supported
Extend the mast again until the load is against the fork face.
The load is now ready to be lifted.
3.6: Travelling Safely with a Load
When travelling with a load always keep the load as low as possible.
Have the load resting on the platforms of the Combilift whenever
possible.
Try to avoid sudden and erratic movements with the machine. Accelerate
and brake as smoothly as possible.
When approaching a junction or corner, slow down, sound the horn and
proceed only when you are sure that your path is unobstructed.
Remember to turn slowly and in the unlikely event of a tip over follow the
procedure illustrated below.
HOLD ON TIGHT
TO STEERING WHEEL
BRACE FEET
LEAN AWAY
FROM IMPACT
LEAN FORWARD
Note
The lift capacity of the Combilift is reduced if the forks are not fully engaged
