C4-C5XL MK3 O&S
4-11
C4000MK3-OM-EN-11
To drain the cooling system, remove the filler cap from the top of the radiator
and the pipe / bung from the bottom of the radiator. The bung is located on the
front of the radiator and can be accessed by removing the radiator access
panel on the right hand side of the truck.
4.7: Hydraulic Oil and Filters
The hydraulic oil used in the Combilift should conform to the International
Standard ISO G344 HV grade oils with improved viscosity / temperature
characteristics. It should also have the correct temperature range for the
ambient temperature in which the machine is being operated. If the operating
temperature is outside the standard range, the standard oil should be
replaced with the correct grade.
Ensure that the correct type of oil is used in the relevant ambient temperature.
The table below indicates a number of commercially available oils and the
temperature ranges that they are suitable for:
AMBIENT
OPERATING
TEMPERATURE
Low Range
-20°C to25°C
-4°F to 77°F
Standard Range
-10°C to35°C
14°F to 77°F
High Range
0°C to45°C
32°F to 113°F
Castrol: H
spin AWH 32 AWH 46 AWH 68
B.P. Bartra
HV 32 HV 46 HV 68
Esso: Univis N 32 N 46 N 68
Mobil 13 M 15 M 16 M
Shell: Tellus oil T32 T46 T68
Texaco HDZ 32 HDZ 46 HDZ 68
Note
The Sequence in which the brand names are listed does not signify any
grading as to their quality or preference.
Coolant Recovery Tank
Filler Cap
Radiator
