C4-C5XL MK3 O&S
3-10
C4000MK3-OM-EN-11
Note
Do not attempt to correct the wheel alignment by adjusting the front master
steerin
g
c
y
linder rod end before tr
y
in
g
the
p
rocedure outlined above.
WARNING
Protective clothing and goggles should be worn and particular care taken not
to come into contact with or spill electrolyte when checking its level.
Keep the battery clean and dry, and terminals free from corrosion. Check that
the ventilation holes in battery caps are clear.
Temperature must not exceed of 38° C (100° F) during charging.
Smoking and the use of naked lights in the charging area are strictly
prohibited.
3.9: Front Wheel Alignment
 If the front wheels are out of alignment select Right/Left mode with the
direction selection switch.
 Wait for the wheels to finish aligning then turn the steering wheel to fully
extend both front steering cylinders. Hold this position for a few seconds.
 Select Forward/Reverse mode on the direction selection switch and wait for
the wheels to finish aligning.
 Check the front wheel alignment. Both front wheels should be aligned
parallel to the platforms.
3.10: Driving Position
 Only operate controls from the correct driving position and do not operate
any control until you are certain of its function.
3.11: Bridge Plates and Dock Boards
 Bridge plates and dock boards must have an adequate safety factor to
support a loaded truck and be secured when in use to prevent accidental
movement.
 Do not exceed the maximum permissible load, which must be clearly
marked on all bridge plates and dock boards.
 The sides of bridge plates, and where possible dock boards, must be
raised to minimise the possibility of the truck being driven over the edge.
 The surface of the above equipment must be of a slip resistant substance.
 Drive slowly when crossing bridge plates and dock boards.
3.12: Lifting the Machine
 Lift the machine only when necessary.
 Check machine weight before lifting
 Use only the two lifting points on the mast and ensure
that the mast is fully retracted and tilted back before
lifting.
