C4-C5XL MK3 O&S
2-1
C4000MK3-OM-EN-11
Section 2: Machine Layout & Operator Controls
It is essential before you start operating the Combilift to be familiar with the
main components and controls of the machine, their function and where they
are located. Figure 2.1 below indicates all of the major components of the
Combilift and figure 2.2 on the following page indicates all of the operator
controls.
2.1: Machine Overview and Components
Figure 2.1: Machine Components Layout
Component List
1. Forks
2. Front Swivels
3. Platforms
4. Hydraulic Tank
5. Bonnet
6. Mast
7. Flashing Beacon
8. Operator Cabin
9. Wipers
10. Side Work Lights
11. Front Work Lights
12. Diesel Tank / LPG Cylinder
13. Step
14. Exhaust
15. Radiator Access Panel
16. Rear Swivel
