5.5: Fuse Box
The diagram and table below show the layout of the fuse box, the rating of
each fuse and the function related to each fuse. See the accompanying spare
parts manual for part numbers if ordering fuses from Combilift.
PLC Loom Fuse Table
Fuse Amps Functio
n
1-Diesel 7.5
Mast Height Override, Dash Display Lights, Glow Plug Light, Glow Plug Relay, PLC Supply
1 – LPG 7.5 Mast Hei
g
ht Override, Dash Displa
y
Li
g
hts, PLC Suppl
y
2 7.5 Jo
y
stick Suppl
y
, Neutral Rela
y
, Reverse Bleepe
r
3 – Diesel 7.5 Pull Hold Solenoid, Fuel Pump, Hi
g
h Temperature En
g
ine Cut-out
3 – LPG 7.5 I
g
nition Coil
4 20 Steerin
g
Solenoid Suppl
y
, PLC Output Suppl
y
5 7.5
Push Button Brake Switch, Inch Pedal Brake Switch, Brake Light, Brake Solenoid Supply
6 10 Wipers
7 15 Front Work Li
g
hts
8 15 Side Work Li
g
hts, Cabin Interior Li
g
ht
9 7.5 Cabin Heater Fan, Cabin Coolin
g
Fan, Optional Radio
10 7.5 Horn
11 7.5 Proximit
y
Switch Suppl
y
, Guide Roller Li
g
ht
12 7.5 Valve Bank Lock Solenoids
13 7.5 Flashin
g
Beacon
14 10 Auxiliar
y
H
y
draulic Functio
n
