C4-C5XL MK3 O&S
1-2
C4000MK3-OM-EN-11
The centre of gravity and therefore stability is also affected by the size,
weight, shape and position of the load; the height to which it is raised;
extension of mast forward and backward; tilt and side shift. Truck movement
such as acceleration, braking, turning and uneven surfaces will also affect
truck stability.
To keep the lift truck stable, the centre of gravity must stay within the area of
the lift truck represented by a triangle drawn between the three wheels. If the
centre of gravity moves forward of the triangle front, the lift truck will tip
forwards. If it moves outside the right or left of the triangle the truck will tip to
the side.
Combilift COG
Combilift & Load
Combined COG
Load COG
Fulcrum
Load COG
Combilift & Load
Combined COG
Combilift
COG
