Comm-Tec MTX88M-N - Page 70

Modular Matrix Switcher
Comm-tec Srl 70 www.comm-tec.it
8.2.10. 4I-DS & 4O-DS
4I-DS
Input
(4) DVI
Input Connector
(4) Female DB24+5
Input Level
T.M.D.S. 2.9V~3.3V
Input Impedance
75Ω
4O-DS
Output
(4) DVI
Output Connector
(4) Female DB24+5
output Level
T.M.D.S. 2.9V~3.3V
Output Impedance
75Ω
General
Gain
0 dB
Bandwidth
340 MHz (10.2 Gbit/s)
Video Signal Format
DVI,HDMI,VGA,C-VIDEO,YPbPr
Max Time-delay
5nS (±1nS)
Crosstalk
<-50dB@5MHz
Color Depth
8 bit
EDID and DDC
Supports Extended Display Identification Data (EDID)
and Display Data Channel (DDC) data using DVI and
HDMI standards. EDID and DDC signals are actively
buffered
HDCP
Compliant with HDCP using DVI and HDMI 1.3
standards
8.2.11. 4I-BT & 4O-BT
4I-BT
Input
(4) HDBT, (4) Audio, (4) RS232
Input Connector
(4) Female RJ45 (with dual-color indicator),
(4) 3.5mm mini jack,
(4) 3-pin pluggable terminal block,
Input Level
T.M.D.S 2.9V～3.3V
Input Impedance
75Ω
Frequency Response
20Hz～20K Hz
4O-BT
Output
(4) HDBT, (4) Audio, (4) RS232
Output Connector
(4) Female RJ45 (with dual-color indicator),
(4) 3.5mm mini jack,
(4) 3-pin pluggable terminal block,
Output Level
T.M.D.S 2.9V～3.3V
Output Impedance
75Ω
Frequency Response
20Hz～20K Hz
General
