Protocol
TCP/IP
Gain
0dB
Bandwidth
10.2Gbps
Resolution
Up to 4Kx2K
Crosstalk
<-50dB@5MHz
Transmission Distance
1080P≤70m, 4Kx2K ≤ 40m
Audio Signal Format
Embedded HDMI audio: PCM, Dobly Digital, DTS, DTS-
HD
Analog audio: PCM
HDMI Standard
HDBT 1.0, HDMI 1.4 and HDCP 1.4
EDID
Support manual EDID management
8.2.12. 4I-BTS & 4O-BTS
4I-BTS
Input
(4) HDBT, (4) Audio, (4) RS232
Input Connector
(4) Female RJ45 (with dual-color indicator),
(4) 3.5mm mini jack,
(4) 3-pin pluggable terminal block,
Input Level
T.M.D.S 2.9V～3.3V
Input Impedance
70Ω
Frequency Response
20Hz～20K Hz
4O- BTS
Output
(4) HDBT, (4) Audio, (4) RS232
Output Connector
(4) Female RJ45 (with dual-color indicator),
(4) 3.5mm mini jack,
(4) 3-pin pluggable terminal block,
Output Level
T.M.D.S 2.9V～3.3V
Output Impedance
75Ω
Frequency Response
20Hz～20K Hz
General
Protocol
TCP/IP
Gain
0dB
Bandwidth
10.2Gbps
Resolution
Up to 1080P@60Hz
Crosstalk
<-50dB@5MHz
Transmission Distance
1080P≤70m
Audio Signal Format
Embedded HDMI audio: PCM, Dobly Digital, DTS, DTS-
HD
Analog audio: PCM
HDMI Standard
HDBT 1.0, HDMI 1.3 and HDCP 1.3
EDID
Support manual EDID management
