ATC200-LITE-USB Teletilt
®
RET System Section 18–Saving Site Report/Configurations
Bulletin 639536 • Revision L October 2014 18-5
5. To view the saved file, launch Excel (or a similar software application) and go to File→Open on
the main menu. Change the directory to look in C:\ATCLite_Site_Files, change the file type to
All Files, and select the desired tabrpt file from the list of files shown.
Click Open (Figure 18-5).
The configuration settings for each actuator are displayed in the order of their address.
Figure 18-5. Opening the Report in Excel.
1. Go to the ATCLite_Site_Files directory.
This directory is located on the C:\ drive.
2. Change file type to All Files (*.*).
This will allow the file saved as a report for Excel to be seen for selection.
3. Select the tabrpt file.
4. Click Open.
