Bulletin 639536 • Revision L October 2014 3-1
Section 3
Uploading Firmware
3.0 Overview
Firmware files for the Andrew Teletilt controller and antenna definition file can be downloaded from
Software web page on the web site
www.commscope.com, by Clicking on the Resources →RE-
SOURCE LIBRARY link, then select the link Software on the right side pane named Resources.
In the Software page click on the link RET Controller Software and Firmware to view the down-
load list and from this select link ATC200-LITE-USB or ATClite v8.0 Software to download the zip
for installation.
3.1 Installing Firmware Updates to Actuators
Firmware updates are occasionally made. Actuators are upgraded following a device scan when the
newer version firmware is available.
Download Phase is new way to install firmware updates. The actuator update status box appears
at the end of the first device search (Figure 3-1). Once the updates are made, this status box is not
seen again, until new actuator updates are made available.
If any of the actuators require updates, they are listed by serial number and the time needed for
installation. Click Yes to confirm updates. If no action is taken, downloads will begin automatically
within 60 seconds.
Note: See Section 1 for installing upgrades to the ATC Lite program.
Figure 3-1. Starting Download Phase.
