Section 6
Device Configuration
After new devices are found and addressed in the ATC Lite program, each device is ready to be
configured. New devices, that have not been configured before, will display a yellow icon with the
status listed as Not Configured in the Device Information list. Not configured devices cannot be
moved until they have been configured successfully.
1. To begin device configuration, click on the device to be configured (Figure 6-1).
2. Click on Edit Selected to open the Configuring Device screen (Figures 6-1 and 6-2).
Figure 6-1. Selecting Device to be Configured.
6-1 October 2014 Bulletin 639536 • Revision L
1. Click on device to be
1. Click Edit Selected.
To Next Page
