8-1 October 2014 Bulletin 639536 • Revision L
Section 8
Changing the Electrical Downtilt on a Group of
Antennas
In addition to changing the downtilt of a single antenna, changes may also be applied to a group of
antennas. The list of antennas that make up the group is defined by three configuration parameters
– Sector ID, Minimum Electrical Tilt, and Maximum Electrical Tilt. Only antennas that are identical in
all three parameters are candidates for a given group move.
1. Switch to RET Device view by selecting ‘Show RETs’ from the drop down list below the Device
Information list.
2. Select a device from the Device Information list that contains the Sector ID and tilt range rep-
resenting the group to be moved (Figure 8-1).
3. Click Move Sector (Figure 8-1).
Figure 8-1. Selecting an Antenna Within a Sector.
1. Click on device within sector to select sector for
2. Click Move sector.
