Bulletin 639536 • Revision L October 2014 13-1
Section 13
Device Configuration with SmartBeam
TM
Antennas
After new devices are found and addressed in the ATC Lite program, each device is ready to be config-
ured. New devices, that have never been configured before, will display the status as Not Configured
in the Device Information list.
1. Switch to RET Device view by selecting ‘Show RETs’ from the drop down list below the Device
Information list.
2. To begin device configuration, click on the device to be configured (Figure 13-1).
3. Click on Edit Selected to open the Configuring Device screen (Figures 13-1 and 13-2).
Figure 13-1. Selecting Device to be Configured.
Note that the SmartBeam antennas shown in Figure 13-1 can have up to three internal
devices. Each device on a SmartBeam antenna will share the same site settings and serial
number.
2. Click Edit Selected.
