Compaq 1000 Series User Manual

Index 7
no orderly shutdown 1-10
overview 1-10
restoring utility power 1-10
repairing the UPS 6-5
replacing batteries
hot-swapping 5-6
installing new batteries 5-12
options 5-5
rack-mountable model
disconnecting the battery
connector, illustrated 5-10
procedure 5-10
removing the front panel,
illustrated 5-10
sliding the battery pack drawer
out, illustrated 5-11
safety issues 5-2, 5-5, 5-6, 5-9,
5-11, 5-12
testing new batteries 5-12
tower model
procedure 5-6
removing the faceplate,
illustrated 5-7
sliding the battery pack out,
illustrated 5-8
REPO See Remote Emergency
Power Off
Reset Defaults, restoring 4-5
RJ-45 receptacle ix
RS-232 port See communications
port
S
safety precautions
battery handling ix
high earth conductor leakage
current ix
Important Safety Information x,
2-2, 2-3
warning to use qualified
personnel ix
weight ix
self-test
initiating See TEST/ALARM
RESET button
meaning of LED display 3-11
serial port See communications
port
Shutdown Delay, selecting 4-4
shutdown sequence, specifying 1-8
Site Wiring Fault LED
explained 3-6
troubleshooting alarm
condition 6-2
Sleep mode
disabling 4-5
enabling 4-5
explained 3-3
specifications
battery C-7
battery runtime C-8
environmental C-9
input C-3
output C-4, C-5
overcurrent protection C-6
overview C-1
physical C-2
STANDBY button
powering the UPS off 3-10
warning concerning use in
Configure mode 4-2, 4-6
Standby mode
after installation 2-13
automatically maintaining
battery charge 3-10
exiting from 3-10
explained 3-2
initiating 3-3
returning to, from Operate
mode 3-10
starting a UPS for the first
time 2-8
storage See care and storage of
batteries
switching the UPS off See
STANDBY button
symbols in text viii
symbols on equipment viii
system administrator
specifying the shutdown
sequence 1-8
using Compaq Power
Management Software 1-7
