3-10 Installing Hardware Options
Writer: Project: Installing Hardware Options Comments:
File Name: E-ch3.doc Last Saved On: 4/23/97 11:22 AM
5. Push the handle on the ZIF socket back into place to secure the
processor.
Figure 3-6. Installing the processor
IMPORTANT: The processor is keyed to ensure correct alignment. Align the
pattern of pins in the processor with the pattern of holes in the socket. The pins
and holes will not line up if the processor is turned the wrong way.
