3-16 Installing Hardware Options
Writer: Project: Installing Hardware Options Comments:
File Name: E-ch3.doc Last Saved On: 4/23/97 11:22 AM
3. Release the original processor from the socket by pulling the handle
on the ZIF socket out and upward.
4. Lift the processor out of the socket
.
Figure 3-12. Releasing the ZIF socket and removing the processor
CAUTION: The handle on the ZIF socket in your server may not be
identical to the handle shown in the drawing. All handle types perform the
same function.
