Technical Reference Guide
D.3 DISPLAY MODES
The 2D graphics display modes supported by the Compaq/NVIDIA Vanta LT Graphics Card are
listed in Table D-1.
Table D-1. NVIDIA Vanta LT 2D Graphics Display Modes
Table D-1.
NVIDIA Vanta LT Display Modes
Resolution Bits per pixel Color Depth
Max. Refresh Frequency (Hz)
640 x 480 8 256 85
640 x 480 16 65K 85
640 x 480 24 16.7M 85
800 x 600 8 256 85
800 x 600 16 65K 85
800 x 600 24 16.7M 85
1024 x 768 8 256 85
1024 x 768 16 65K 85
1024 x 768 24 16.7M 85
1152 x 864 8 256 85
1152 x 864 16 65K 85
1152 x 864 24 16.7M 85
1280 x 1024 8 256 85
1280 x 1024 16 65K 85
1280 x 1024 24 16.7M 85
1600 x 1200 8 256 85
1600 x 1200 16 65K 75
Compaq Personal Computers
Changed - October 2000
D-3
