Chapter 2 System Overview
2.3 MECHANICAL DESIGN
These systems are available in three form factors:
♦
♦
♦
Small Form Factor – a small-footprint desktop designed for environments where both
performance and space are critical issues.
Desktop – a low-profile ATX-type desktop that satisfies standard expandability needs.
Configurable Minitower – an ATX-type unit providing the most expandability and being
adaptable to desktop (horizontal) or floor-standing (vertical) placement.
The following subsections describe the mechanical (physical) aspects of the Compaq Evo models.
CAUTION: Voltages are present within the system unit whenever the unit is plugged
into a live AC outlet, regardless of the system's “Power On” condition. Always
!
disconnect the power cable from the power outlet and/or from the system unit
before handling the system unit in any way.
NOTE: The following information is intended primarily for identification purposes
only. Before servicing these systems refer to the applicable Maintenance And
Service Guide. Service personnel should review training materials also available on
these products.
Compaq Evo and Workstation Personal Computers
Featuring the Intel Pentium 4 Processor
Second Edition – January 2003
2-4
