Appendix H Compaq/Matrox G200 MMS Quad-Head PCI Graphics Card
H.3 DISPLAY MODES
The graphics display modes supported by each monitor port on the Matrox G200 MMS Graphics
card are listed in Table H-1.
Table H-1. Matrox G200 MMS Graphics Display Modes
Table H-1.
Matrox G200 MMS Graphics Controller Display Modes
Resolution Bits per pixel Color Depth
Max. Vertical
Refresh Freq. [1]
Monitor
Support
640 x 480 8 256 200 Hz Analog or Digital
640 x 480 16 65K 200 Hz Analog or Digital
640 x 480 24 16.7M 200 Hz Analog or Digital
640 x 480 32 16.7M 200 Hz Analog or Digital
800 x 600 8 256 200 Hz Analog or Digital
800 x 600 16 65K 200 Hz Analog or Digital
800 x 600 24 16.7M 200 Hz Analog or Digital
800 x 600 32 16.7M 200 Hz Analog or Digital
1024 x 768 8 256 140 Hz Analog or Digital
1024 x 768 16 65K 140 Hz Analog or Digital
1024 x 768 24 16.7M 140 Hz Analog or Digital
1024 x 768 32 16.7M 140 Hz Analog or Digital
1152 x 864 8 256 120 Hz Analog or Digital
1152 x 864 16 65K 120 Hz Analog or Digital
1152 x 864 24 16.7M 120 Hz Analog or Digital
1152 x 864 32 16.7M 120 Hz Analog or Digital
1280 x 720 8 256 100 Hz Analog or Digital
1280 x 720 16 65K 100 Hz Analog or Digital
1280 x 720 24 16.7M 100 Hz Analog or Digital
1280 x 720 32 16.7M 100 Hz Analog or Digital
1280 x 1024 8 256 100 Hz Analog or Digital
1280 x 1024 16 65K 100 Hz Analog or Digital
1280 x 1024 24 16.7M 100 Hz Analog or Digital
1280 x 1024 32 16.7M 100 Hz Analog or Digital
1600 x 1024 8 256 100 Hz Analog only
1600 x 1024 16 65K 100 Hz Analog only
1600 x 1024 24 16.7M 100 Hz Analog only
1600 x 1024 32 16.7M 100 Hz Analog only
1600 x 1200 8 256 90 Hz Analog only
1600 x 1200 16 65K 90 Hz Analog only
1600 x 1200 24 16.7M 90 Hz Analog only
1800 x 1440 8 256 70 Hz Analog only
1800 x 1440 16 65K 70 Hz Analog only
1920 x 1080 8 256 80 Hz Analog only
1920 x 1080 16 65K 80 Hz Analog only
1920 x 1080 24 16.7M 80 Hz Analog only
1920 x 1200 8 256 76 Hz Analog only
1920 x 1200 16 65K 76 Hz Analog only
NOTE:
[1] Value reflects hardware capabilities only. May be restricted to lower frequency by
operating system.
Compaq Personal Computers
Original - March 2002
H-4
