Technical Reference Guide
Figure 2-5 shows the layout for the Configurable Minitower in the minitower configuration.
Features include:
♦ Externally accessible drive bay assembly may be configured for minitower (vertical) or
desktop (horizontal) position.
♦ Easy access to expansion slots and all socketed system board components.
Processor/Heat Sink/Fan
Assembly
PCI Slot 1
PCI Slot 2
PCI Slot 3
PCI Slot 4
PCI Slot 5
AGP Slot
Chassis Fan
Hood Lock
Solenoid
(Optional)
Power Supply
Back
Front
Drive Lock
Externally Accessible
Drive Bays
Internal
Drive Bays
Speaker
Figure 2–6. Configurable Minitower Chassis Layout, Left Side View (Minitower configuration)
Compaq Evo and Workstation Personal Computers
Featuring the Intel Pentium 4 Processor
Second Edition - January 2003
2-9
