Theinstallationsiteofthesteamhumidierdependslargelyonthelocationofthesteamdistributor
(seechapter5.4).Toensure proper functioningofthesteamhumidierandtoobtain an optimal
efciency,thefollowingpointsmustbeconsideredandobservedwhenchoosingthelocationfor
thesteamhumidier:
– Installthesteamhumidiersothatthelength of the steam hose is kept as short as possible
(max. 4 m)andthattheminimum bend radius (R= 300 mm) and up-slope (20 %) or down-
slope (5 %)ofthesteamhoseisobserved(seechapter5.4.5).
– ThesteamhumidiersCondairEL2aredesignedforwall-mounting.Makesurethattheconstruc-
tion(wall,pillar,oor-mountedconsole,etc.)towhichthehumidiersaretobemounted,offers
a sufcientlyhighload-bearingcapacity(takenoticeoftheweightinformationfoundinthe
dimensionsandweightstableabove),andissuitablefortheinstallation.
CAUTION!
Donotmountthesteamhumidierdirectlytotheventilationduct(insufcientstability).
– ThebackpaneloftheCondairEL2isretainingheatduringoperation(max.surfacetemperature
ofthemetalhousingapprox.60-70°C).Makesure,therefore,thattheconstruction(wall,pillar,
etc.)towhichtheunitsaretobemounted,doesnotconsistofheat-sensitivematerial.
– Installthesteamhumidierinsuchamannerthatitisfreely accessiblewithsufcientspace
availableformaintenancepurposes(refertotheaboveillustrationforminimumdistances).
– The Condair EL2 is protected according to IP20.Makesuretheunitsareinstalledinadrip-proof
location and the admissible ambient conditions are complied with.
– ThesteamhumidierCondairEL2mayonlybeinstalledinroomswithaoordrain.
CAUTION!
If for some reason the Condair EL2 must be installed in a location without oor drain, it is
mandatorytoprovidealeakagemonitoringdevicetosafelyinterruptthewatersupplyincase
ofleakage.
– WhenxingtheCondairEL2useonlythexingmaterialssuppliedwiththeunit.Ifxingwith
thematerialssuppliedisnotpossibleinyourparticularcase,selectamethodofxingthatisof
similar stability.
– TheCondairEL2isdesignedforinstallationandoperationwithinbuildings(admissibletemperature
rangeseechapter10.1).ForoutdooroperationtheCondairEL2mustbeplacedinaweather
protectivehousing.Ifambienttemperaturesnearorbelowthefreezingpointhavetobeexpected,
theprotectivehousingmustequippedwithathermostatcontrolledheatingofsufcientcapacity.
The water supply pipe must be equipped with a trace-heating and must be insulated up to the
protective housing.
