Condair EL2 - 17 7.3.5 Removal and Installation of the Inlet Valve

57
7.3.5 Removal and installation of the inlet valve
Forremovingtheinletvalvethesteamcylindermustberemovedrst(seechapter7.3.1).
1. Detachelectriccables(polarityofthecablesmustnotbeobserved).
2. Releasehoseclampandremovethehosefromtheconnector.
3. Unlockunionnutofthewaterpipeandremovewaterpipe.
4. Loosen the two screws with Phillips screwdriver, then remove inlet valve.
The installationoftheinletvalvefollowsthereversesequence.Theunionnutofthewaterpipe
must be tightened by hand only.
2
4
3
1
