7.3 Removing and installing parts for maintenance
7.3.1 Removal and installation of the steam cylinder
1. Useascrewdrivertoundothetwoscrewsxingthefrontpaneltotheunit,thenremovethefront
panel.
2. Release the hose clamp on the steam hose using a screwdriver, then detach the steam hose
fromthesteamoutletconnectionofthesteamcylinder.
3. Removeallplugsfromtheelectrodesandfromthelevelsensor.
4. Loosenthescrewofthesteamcylinderxingdevicebyafewturns,thenpushthexingdevice
upwards until it comes loose and remove it.
1 2
3 4
