5. Carefullyliftsteamcylinderawayfromthecylinderreceptacle,thenremoveittothefront.
CAUTION!
Putsteamcylinderdowncarefullytoavoiddamagetothelowerconnectionpiece!
Installationofthesteamcylinderfollowsthereversesequence.Observe the following:
– Beforeinstallingthesteamcylinderintheunit,checktheO-ringofthecylinderreceptaclefor
damageandreplaceifnecessary.
– MoistentheO-ringofthecylinderreceptaclewithwater(donotusegreaseoroil),theninsert
steam cylinder into the receptacle and push it down to the stop.
– Attach the electrode plugs and the level sensor plug to the respective electrode and sensor con-
nectionsaccordingtothefollowingtable.
Steam cylinder type
A342 / D342 A343 / D343
A363 / D363
A444 / D444
A464 / D464
A654 / D654
A644 / D644
A664 / D664
A674 / D674
5
Sensor
white
brown
red
black
Sensor
white
brown
red
black
brown
red
black
Sensor
white
brown
black
