Condair EL2 - Installing the Steam Distributors

31
Inpositioningthesteamdistributionpipes,thefollowingdimensionsshouldbeobserved:
h
min
h
min
1/2
H
1/2
H
1/3
2/3
H
H
2/7
2/7
3/7
1/3
H
1/3
1/3
2/7
2/7
3/7
H
1/2
1/2
h
min
g
min
g min.= 100 mm
h min.= 85 mm
H min.= 250 mm H≥400mm H min.= 200 mm
H min.= 400 mm H min.= 350 mm H min.= 300 mm
5.4.3 Installing the steam distributors
Detailedinformationontheinstallationofsteamdistributionpipes41-..,61-.../81-...andOptiSorp
steamdistributionsystemcanbefoundintheseparatemountinginstructionsforthisproducts.
Note: When locating the OptiSorp steam distribution system please note the instructions in the
separatedocumentationforthisproduct.
Guidelines for dimensioning the ventilation ducts
– Tofacilitatetheinstallationofthesteamdistributionpipesandforcontrolpurposes,asufciently
sized control opening should be planned.
– Withintherangeofthehumidicationdistance,theventilationductshouldbewaterproofed.
– Airductspassingthroughcoldroomsshouldbeinsulatedtopreventthehumidiedairfromcon-
densing along the duct wall.
– Poorairowconditionswithintheairduct(e.g.
causedby
obstacles,tightbends,etc.)canlead
tocondensationofthehumidiedair.
– Steam distribution pipes must not be mounted to round ducts.
Ifyouhavequestionsrelatingtothedimensioningofventilationductsincombinationwithsteam
humidiersCondairEL2,contactyourCondairsupplier.
