30
Minimum distances to be observed
Topreventthewatervapour,thatisemittingfromthesteamdistributionpipe,fromcondensingon
downstream system components, a minimum distance to the steam distribution pipe must be observed
(dependsonthehumidicationdistance“B
N
”).
before/after constriction after expansion before bend
before branch before diffuser before control sensor
 before/afterlter/register before/afterfan,zoneexit
2,5 x B
N
beforeaerosollter
Installation notes and dimensions
Thesteamdistributionpipesaredesignedforeitherhorizontalinstallation(ontheductwall)or,with
accessories,forverticalinstallation(intheductoor).Theoutletoricesshouldalwayspoint
upwardsandatrightanglestotheairow.
Ifpossible,thesteamdistributionpipesshouldbeinstalledonthepressure sideoftheduct(max.
duct pressure 1500 Pa).Ifthesteamdistributionpipesareinstalledonthesuctionsideof
theduct,

the maximum vacuum must not exceed 800 Pa.
Selectalocationfortheinstallation,tailoredtosuityourduct(seethefollowingillustrations)and
positionthesteamdistributionpipesintheductsothatauniformdistributionofsteamisachieved.
1.5 x B
N
*
B
N
B
N
5 cm
