5.3.2 Mountingthehumidier
Procedure
1. Mark the attachment point “A” on the wall.
2. Drillholeforattachmentpoint“A”(diameter:8mm,depth:40mm).
3. Insert the supplied plastic plug, and tighten the screw until the distance between the wall and the
screw head is 4 mm.
4. Unlockthetwoscrewsxingthefrontpaneltotheunit,thenremovethefrontpanel.
5. Hang up the unit onto the screw and adjust it horizontally and vertically using a spirit level. Then,
markthexingpoints“B”.
6. Drilltheholesforthexingpoints“B”(diameter:8mm,depth:40mm).
7. Insert the supplied plastic plugs, and tighten the screws until the distance between the wall and
the screw head is 4 mm.
8. Hangtheunitupontothescrews.Beforetighteningthescrews,readjusttheunitwiththespirit
level.
9. Reattachthefrontpanelandsecureitwiththetwoscrews.
Dimension Housing size
small large
a 189 mm 246 mm
b 61 mm 52 mm
c 490 mm 547 mm
d 120 mm 180 mm
e 120 mm 180 mm
d
e
b
c
a
A
B
B
