Table 5-7 Drive digital I/O terminal, enable input and relay
OFF (0) = Terminal inactive
On (1) = Terminal active
Digitax ST has a dedicated hardware enable/SAFE TORQUE OFF (SECURE DISABLE) input which always controls Pr 6.29. If the enable is inactive
the IGBT firing signals are turned off without software intervention. As default (Pr 8.10 = 0) the drive is in the inhibit mode when the enable is inactive.
Setting this parameter to one causes the enable to behave as an Et trip input. When the input becomes inactive an Et trip is initiated. This does not
affect Pr 10.32 (Et trip parameter), therefore an Et trip can be initiated in this mode either by making the enable inactive or setting Pr 10.32 to one.
Terminal + type
I/O state Invert Source / destination Output select
Pr Pr Default Pr Default Pr Default
T24 input / output 1 Pr 8.01 Pr 8.11 0Pr 8.21 Pr 10.03 - Zero speed Pr 8.31 1
T25 input / output 2 Pr 8.02 Pr 8.12 0Pr 8.22 Pr 10.33 - Drive reset Pr 8.32 0
T26 input / output 3 Pr 8.03 Pr 8.13 0Pr 8.23 Pr 6.30 - Run forward Pr 8.33 0
T27 input 4 Pr 8.04 Pr 8.14 0Pr 8.24 Pr 6.32 - Run reverse
T28 input 5 Pr 8.05 Pr 8.15 0Pr 8.25 Pr 1.41 – Local/remote
T29 input 6 Pr 8.06 Pr 8.16 0Pr 8.26 Pr 6.31 – Jog
T41 / 42 Relay Pr 8.07 Pr 8.17 0Pr 8.27 Pr 10.01 – Drive ok
T22 24V output Pr 8.08 Pr 8.18 1Pr 8.28 Pr 0.00
T31 SAFE TORQUE OFF
(SECURE DISABLE)
Pr 8.09
8.01 T24 digital I/O 1 state
8.02 T25 digital I/O 2 state
8.03 T26 digital I/O 3 state
8.04 T27 digital input 4 state
8.05 T28 digital input 5 state
8.06 T29 digital input 6 state
8.07 Relay status
8.08 T22 24V output state
8.09 Drive enable indicator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default See table
Update rate 4ms write
8.10 Drive enable mode select
Coding Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default OFF (0)
Update rate Background read
