Kit Installation

2-10 February 2016 | 256574-ENG R01

Item Qty. Description Photo

J 2 Lamp Canopy Support

K 1 Lamp Canopy

L 1 Unifloor Cassette

M 16 Wire Shelf Support Bracket

N 4 Wire Shelf

2.3.2 PG Kit Installation

Open the chamber door, remove the kit package, and inspect the chamber and kit parts. Contact

Conviron immediately is any damage is found, or if any parts are missing.
