A1000 INSTALLATION, OPERATION, & MAINTENANCE MANUAL
February 2016 | 256574-ENG R01 3-1
3 CHAMBER INSTALLATION REQUIREMENTS
A1000 units must be placed in ventilated areas. The ideal temperature around the equipment is
21ºC. Although it will perform at higher ambient temperatures, it is recommended that the product
be placed in areas that have circulating air.
3.1 Chamber Placement
Conviron guarantees performance of the chamber for ambient temperature conditions between
15°C and 30°C. It is important to ensure that the room in which the chamber is located adheres to
these environmental conditions.
A1000 products will dissipate up to 2400 W to ambient.
3.1.1 Chamber Clearance
At least 1 ft. (300 mm) must be left clear behind the back wall.
At least 1 ft. (300 mm) must be left clear above the unit.
At least 2” (50 mm) must be left clear on each side of the A1000 when the PG Kit is
installed. Note – if any kit other than the PG Kit is installed, no side clearance is
required.
3.1.2 Power Supply
All A1000 products are single phase and delivered to the market with one of two options.
120VAC-1-60 Hz – 2 wire plus ground – 20 Amp overcurrent protection
230VAC-1-50Hz - 2 wire plus ground – 16 Amp overcurrent protection
This unit will tolerate ±10% voltage fluctuation from the rated voltage on the serial plate. A voltage
stabilizer must be used if the fluctuation is greater than ±10%. Failure to do so can result in
serious damage to the compressor and electronic components and will void warranty.
Disconnect switch must be sized by a qualified, local electrician.
Ensure at least 4” (100mm) of free space around the exterior side walls of a chamber
with a PG kit to facilitate proper air circulation. Inadequate air circulation and cooling
inside the chamber will result if this space is not provided.
