A1000 INSTALLATION, OPERATION, & MAINTENANCE MANUAL

February 2016 | 256574-ENG R01 8-3

8.1 Terms & Definitions

Table 8-1 Terms and Definitions

Term Definition

%RH Humidity level expressed as a percentage of the maximum humidity level



Greek letter Phi – SI prefix for electrical phase



Greek letter Mu – SI prefix for micro

C

Celsius Degrees

A Amperes

AC Air cooled condenser unit

AR Arabidopsis

CFC Chlorofluorocarbon

ESD Electrostatic Discharge

EU European Union

GR Ground

Hz Hertz

ID Inside Diameter

IN Incubator

l/hr Liter per hour

lpm Liter per minute

LT Low temperature

mA milliAmperes

mm millimeter

OD Outside Diameter

PG Plant growth, for use with tall plants

psi Pounds per square inch

PVC Polyvinyl Chloride

RoHS Restriction of Hazardous Substances Directive

TC Tissue Culture

UPS Uninterruptable Power Supply
