Technical Specifications

8-2 February 2016 | 256574-ENG R01

Temperature and Humidity Rages

PG Kit AR Kit TC Kit IN Kit

Additive Humidity

(lights on)

75% 75% 75% 75%

Light intensity

(mol: @25C)

700 500 225 125

Additive Humidity

(lights off)

Resultant to 90% RH – limited by +25C dew point

Additive Humidity

Tolerance

± 6%

Temp (lights on)

10C – 45C

Temp Tolerance

±0.05C

Specifications

A1000

PG Kit AR Kit TC Kit IN Kit

Lighting

# of Light Canopies /

Fixtures

1 canopy 2 canopies 4 canopies

4 fixtures

(1 per shelf)

Lamps per Canopy /

Fixture

14 6 4 2 per fixture

Airflow Direction Uniform Upward Uniform Horizontal Uniform Vertical Uniform Horizontal

Growth Envelope

Shelves 1 adjustable 2 adjustable 4 adjustable 4 adjustable

Total Growth Area

(ft

/ m

)

5.65 / 0.5 11.3 / 1.05 22.6 / 2.1 22.6 / 2.1

Growth Height

(in. / mm)

42 / 1065 18 / 460 6 / 122 10 / 250

Growth Volume

(ft

/ Litres)

29.2 / 826


