Kit Installation

2-26 February 2016 | 256574-ENG R01

2.5 Arabidopsis – AR Kit

Depending on order options, the chamber may be delivered with the kit installed. The kit is easy to

install using only a Phillips screwdriver.

2.5.1 AR Kit Parts List

Item Qty. Description Photo

A 1

Back Wall Plenum Bottom

Support

B 1 Back Wall Plenum

C 16 Screw M4 x 8mm, Pan Head

D 2 Lamp Canopy Support

E 2 Lamp Canopy

F 8 Wire Shelf Support Bracket

G 2 Wire Shelf
