Troubleshooting

6-2 February 2016 | 256574-ENG R01

Chamber lights not working

1. Ensure that the chamber is plugged into the wall outlet and that the main disconnect switch is ON.

2. Ensure the lamp canopy is plugged into the chamber wall.

3. Check and replace the dark bulb(s).

4. Check the light levels settings on the controller.

Still no lights

Contact service or Conviron.
