How to do it correctly
User manual 180
► Removing and fitting the suction panel on table-top appliances
Hot surfaces
Risk of burns from high temperatures inside the oven and on the inside of the appliance door
You may get burnt if you touch any of the interior parts of the oven, the inside of the appliance door or
any parts that were inside the oven during cooking.
f Wear personal protection equipment as specified in safety regulations.
Materials required
You need the following materials:
Suitable tool for undoing the screws e.g. wrench
Removing the suction panel
To remove the suction panel, follow the steps below:
Step Action Illustration
1 Release the catches, top (1) and bottom (1), using the tool,
and hinge out the suction panel into the oven (2).
2
Push the suction panel upwards and remove it (3).
Fitting the suction panel
To fit the suction panel, follow the steps in the reverse order.
