Specification
Loop Load Min Nom Max Units
Quiescent Current 310
Operating Voltage
18 30 V DC
Output Relay
Switching Voltage 24 30 V DC
Contact Rating 1 A
Switching Power 30 W
Environmental
Operating Temperature -10 +60 °C
Humidity (Non Condensing) 95 %RH
Standards
EN54 : Pt2 & 4
BS5839 : Pt1 (Installation)
Compatibility
Suitable for use with Cooper Analogue Addressable Fire Systems
Physical
Dimensions 63mm x 35mm x 18.5mm
Weight >0.1kg
Ingress Protection IP40
Short Circuit Isolator
This addressable device contains an integral short circuit isolator, which operates between the – IN terminal and the
– OUT terminal. The isolator operates in conjunction with Cooper Analogue Addressable Control Panels when a
low parallel resistance fault of typically 200? is present between the +VE and –VE of the loop wiring.
–
Short Circuit Isolation Data
(Integral with each device)
Total Loop Resistance for correct
operation of short circuit isolator
50 (max)
Continuous Current allowable through
isolator
700mA (max)
Isolator Resistance in closed state 0.13 (max)
Leakage Current into direct short
circuit with isolator open
13mA (max)
Parallel Fault Resistance to be seen at
the Control Panel for isolators to open
200 (typ)
Drg ref PR205-118-514-01
