CAS380 Sounder Base Specification
Supply Voltage
Cable Size / type
Standby current
Operating temperature
Material
Environment Category
Sound output @ +/- 3dB
(Set by panel)
Compliance
Order Codes
CAS380
CAS380/COV
Addressable sounder base
Cover for sounder base (5 pack)
Installation Details
50
60
70
1
80
. Mounting bas e
(i) Knock-out the required
fixing holes
(ii) Fix to mounting surface
using two suitable screws
If the base deforms on an
uneven surface, loosen
the screws or move to a
more flat position.
2. S ounder as s embly
(i) Clip sounder onto base
If sounder needs to be
removed, use a small
screwdriver to unclip.
3. Connection details
4. L ock ing tab (optional)
71
61 -
43
102O
Sounder and Cover Sounder and Detector
Dimens ions
25-5654 C
Fit the locking tab into the square
hole on the sounder.
Finish assembly as stage 5.
Remove by inserting a suitable tool
(eg thin screwdriver) into the hole in
the detector or cover, then rotate
detector or cover anti-clockwise.
5. Fitt ing detector or cover
: 17 ~ 32 Vdc
: 0.5 ~ 2.5mm/ FIRETUF, FP200 or MICC
: < 320 uA
: -10 to +55 degrees C (95%RH)
: ABS/PC FR Plastic
: Type A / IP21C
: Low volume : 84dB @ <4mA
: Medium volume : 92dB @ <8mA
: High volume : 95dB @ <12mA
: EN54-3 Fire Alarm Device - Sounder
- + - +
in
out
Loop Start
Loop Finish
Cooper Fire Systems
Analogue Addressable
Panel
S+
S-
F-
F+
102O
Locking tab
release hole
WARNING: Do NOT use high voltage testers if ANY
equipment is connected to the system.
Earth screen must be continuous
along entire length of loop.
2
2
3
3
E
E
4
4
1
1
- + - +
in
out
Tones
(set by panel)
: Continuous 910Hz
: Pulsed 910Hz / 0Hz pulse 1Hz
: Two tone 610 / 910Hz @ 1Hz cycle
: Slow whoop 500-1200Hz in 3.5 seconds / 0.5secs gap
Do not use this
connection
Do not use this
connection
Security House
Vantage Point Business Village
Mitcheldean
Glos.
GL17 0SZ
Tel: + 44 (0) 1594 541900
Note: Polar dispersion information available in the Technical manual.
(Ref:M05-010)
0832-CPD-0155
CE marking under the CPD was affixe d on : (See batch code on product)
