CAB382 Beacon Specification
Supply Voltage
Cable Size
Recommended cable
Material
Standby current
Alarm current
Flash frequency
Operating temperature
IP Rating
Order Codes
CAB382 Addressable Beacon
Installation Details
1. Mounting bas e
(i) Fix to mounting surface using two suitable
screws - the rear gasket fits underneath the base,
and the sounder gasket fits inside the base.
2. Connection details
(i) Earth screen must be continuous along entire length of loop.
Dimens ions
25-5657 A
3. Fitting b eacontobase
:1 7~32Vdc
: 0.5 ~ 2.5mm
: FIRETUF, FP200 or MICC
: Polycarbonate/ABS FR
: < 250 uA
:<4.1mA
:1/2Hz
: -10 to +55 degrees C (95%RH)
: IP54
WARNING:
Do NOT use high voltage testers if ANY equipment is connected
to the system.
Cooper Fire Systems
Analogue Addressable
Panel
50
OPEN
CLOSE
Care should be taken to ensure the cable
does not put stress on the circuit board.
93?
53
Cable entry
hole
-+
LOOP
IN
LOOP
OUT
-+
Rear
Gasket
Sounder
Gasket
Security House
Vantage Point Business Village
Mitcheldean
Glos.
GL17 0SZ
Tel: + 44 (0) 1594 541900
IN
Earth
Earth
OUT
