All dimensions are in inches (millimeters).
Appendix D—Outline Dimensions
Model FD891 Bare with Flywheel
2-1/8 (54)
21.2
(539)
diameter
14-1/2 (369)
9-1/2 (235) 14 (356)
5-1/2
(140)
6
(152)
6
(152)
8-1/4
(210)
43-3/16
(1,097)
35-5/8
(905)
5-3/8
(137)
5-3/8
(137)
1
(25)
4-3/4
(121)
Outlet:
2" Class
300 RF
ange
Discharge
pressure
gauge
(optional)
Inlet:
2" Class
300 RF
ange
Suction
pressure
gauge
(optional)
Suction
valve
unloaders
(optional)
Four
9/16 (14)
mounting
holes
Compressor
wrench
Crankcase
oil gauge
Crankcase
oil heater
(optional)
