All dimensions are in inches (millimeters).
Appendix D—Outline Dimensions
Model FD891 with 103 Mounting
56 (1,423)
30 (762)
61 (1,550)
Overall with switches
39 (991)
Overall
5-3/4
(147)
7-1/16
(180)
6
(152)
6
(152)
41-5/8
(1,058)
Outlet:
2" Class 300
RF ange
Inlet:
2" Class 300
RF ange
Outlet
pressure
gauge
Inlet
pressure
gauge
Suction valve
unloaders
(optional)
49-3/16
(1,250)
overall
52
