Instruction Manual | 31
10.0 TechnicalSpecications
Device
Model Videodrop
Country of origin France
IP code IPX0: the device is not protected against liquids
Mode of operation Continuous service
Minimal system requirements Windows® 10 or 11 PC
16 GB of RAM
Hard drive with at least 4 TB (terabyte) storage capacity
Processor with at least 8 cores (min. of 3.6 - 5 GHz of frequency per core)
USB SS port available
Measurement ranges
Size of Biological Nanoparticles
(Hydrodynamic diameter)
80 to 500 nm
Concentration 1.10
8
to 1.10
10
part./mL
Electrical
Power supply 120V, 60 Hz
230V, 50 Hz
Usable power 30 VA
External power supply
Tension 12V
Power 36 W
Tolerance ±10%
Mechanical
Weight 39.69 lbs. (18 kg)
Material Painted aluminum
Dimensions (L x W x H) 11.82 x 11.82 x 31.15 in. (30 x 30 x 79.1 cm)
Optical
Maximum output power 4.5 W
Wavelength 450 nm
Risk group 3 (according to EN 62471)
Environmental
Operating temperature 2 to 40°C
Operating humidity 30% to 75% relative humidity (non-condensing)
Storage and transport temperature -20 to 60°C
Storage and transport humidity 30% to 85% relative humidity (non-condensing)
Additional information
Cables Supplied 1 power cable with a 12V transformer
1 USB cable 2.0 micro B (1.5 m)
1 USB cable 3.0 micro B (2 m)
Consumables
Boxes of sample slides 1 box of 50 sample slides
Packaging
Videodrop parcel and protective foam
(L x W x H)
34.9 x 16.8 x 15 in. (88.5 x 42.5 x 38 cm)
