MULTIFUNCTION PANEL
Speed sensor
- Pulse inputs coming from a Hall effect sensor.
- The sensor’s output has to be of the open manifold type.
- The instrument has 3 connector pins dedicated to the speed sensor:
• Pin-6 - “Speed_sensor_supply” to feed the Hall sensor.
• Pin-7 - “Speed_sensor_input” for the input of pulses from the sensor.
• This input has an internal pull-up resistor of 1 kOhm connected to Pin-6.
• Detection of low level of input: < 2 V
• Detection of high level of input: > 6 V
• Pin-8 - “Speed_sensor_GND” to connect the sensor’s ground.
Speedometer
- The speed will be indicated in analogue form using a needle backlit in red.
- The dial of the speedometer has a linear scale of 0 to 80 km/h.
- Relationship (pulses / return): 50
- By default, the size of the wheel perimeter is 2042 mm.
- The speed is displayed with a 10% advance (in respect of the actual speed).
- The minimum speed displayed will be 3 km/h.
