Odometer
- The indicator has 6 digits (without a decimal point) + the km symbol.
- The counter is displayed without zeros to the left.
- The value of the odometer is displayed with a 1% advance (with respect to the actual kilometrage).
- When the odometer reaches 999999 km, it will stop counting and will not restart.
- When the odometer is shown, it will display the ODO symbol.
- We can access TRIP-1 from the odometer by pressing MODE (<2 s).
- We can access the running hours from the odometer by pressing TRIP (>2 s).
- We can change the time from the odometer by pressing MODE (>2 s).
Hours of operation
- The indicator has 6 digits, including a decimal point indicating the number of 10-minute fractions that have elapsed. It also shows the
letter “h’’ for the hours of operation.
- The counter only increases in value when the engine is started using the ignition key.
- The counter is displayed without zeros to the left.
- When the counter reaches 9999.5 hours, it will remain xed at this value.
- We can access the odometer from the hour meter by pressing TRIP (>2 s).
- We can access TRIP-1 from the hour meter by pressing MODE (<2 s).
- We can change the time from the hour meter by pressing MODE (>2 s).
TRIP-1 (partial counter 1)
- The indicator has 4 digits (with a decimal point) + the KM symbol.
- The counter is displayed without zeros to the left.
- The value of the partial counter is displayed with a 1% advance (with respect to the actual kilometrage.
- When the partial counter reaches 999.9 km, the counter returns to 0.
- Pressing on the TRIP button (for >2 s) resets the counter to 0.
- When the partial counter is shown, the TRIP 1 symbol is shown.
- We can access TRIP-2 from TRIP-1 by pressing MODE (<2 s).
MULTIFUNCTION PANEL
