MULTIFUNCTION PANEL
TRIP-2 (Partial counter 2)
- The indicator has 4 digits (with a decimal point) + the KM symbol.
- The counter is displayed without zeros to the left.
- The value of the partial counter is displayed with a 1% advance (with respect to the actual kilometrage.
- When the partial counter reaches 999.9 km, the counter returns to 0.
- Pressing on the TRIP button (for >2 s) resets the counter to 0.
- When the partial counter is shown, the TRIP 2 symbol is shown.
- We can access the ODOMETER from TRIP-2 by pressing MODE (<2 s).
- If we press MODE for 10 seconds, we can congure the wheel size setting.
- We have a 10-second time-out if no button is pushed.
Maintenance service
- Maintenance intervals have been established for every 1500 km, each year “1 YEAR” or every 100 hours of operation.
- When you have travelled 1300 km, the service symbol will ash on the screen.
- When you have travelled 1500 km, the service symbol will remain lit.
- When there are 30 days left before the service is due, the service sign will ash with the “1 Year” symbol.
- If 1 year goes by before you have travelled the kilometres at which maintenance is due, the service symbol will activate with the text “1 YEAR”.
- The operating hours indicator will begin at 100 and will decrease until you reach 0 h. When you reach this value, the service icon will remain on as
will the zero indication.
- The hours remaining before maintenance is due will appear for 5 seconds when we put the key in.
- During these 5 seconds, if we press the MODE button for less than two seconds, the remaining km before the service is due will appear, with a “-“
sign or the km that have been exceeded, preceded by a letter “E”.
- During these 5 seconds, if we press the TRIP button for less than two seconds, the remaining days before the “1 YEAR” service is due will appear,
with a “-“ sign or the days that have been exceeded, preceded by a letter “E’’.
- When the days of use are 365 or more, both icons will remain turned on.
- The update of the days of use for the service is done with the key cycle.
