MULTIFUNCTION PANEL
Gear
The vehicle is automatic.
The gear will be indicated on the screen by an alphanumeric digit that can display:
- N to indicate that you are in NEUTRAL.
- R to indicate that you are in REVERSE GEAR.
- L to indicate that you are in SHORT GEAR.
- H to indicate that you are in LONG GEAR.
The change of gear indication will have a delay of 300 ms.
If a problem with the sensor is detected persistently, such as open circuit or short circuit, the gear indication will disappear after 1 second. In the
event of a system reset, the indication will reappear after 1 second.
Revolution counter (RPM)
The instrument displays the engine revolutions via a bar indicator.
It has a total of 20 bars that will serve to indicate the range of 0 to 10000 rpm (one bar is equivalent to 500 rpm).
Only 10 bars are used for this instrument (up to 5000 rpm), since this vehicle’s the maximum revolutions will be 4000 rpm.
The RPM indication increases from left to right.
The ratio to obtain the revolutions is RPM = 6 x Hz alternator.
GEAR SENSOR INDICATION DISPLAY RESISTANCE (OHM)
2
3
4
5
R
N
H
L
470
820
1500
2700
