Fuel
The fuel level gauge is resistive. The display bars will be indicated as per the attached table.
- There are 8 bars on the display, with the letters E (Empty) and F (Full) plus the fuel icon.
- The fuel reserve alarm LED light will come on when 1/8 of the tank remains.
- When a short circuit is detected, all the bars and the fuel LED will ash.
- When an open circuit is detected, bars 1 and 8 and the fuel LED will ash.
MULTIFUNCTION PANEL
8
7
6
5
4
3
2
1
0
FUEL LEVEL GAUGE
RESISTANCE RANGE
UPDATE TIME
OPEN CIRCUIT DETECTION
SHORT CIRCUIT DETECTION
48
78
109
139
154
174
195
276
338
Variable resistor
3 – 338 ohm
30 seconds
>500 ohm
2 ohm
±2.5 ohm
±3.0 ohm
±3.5 ohm
±3.5 ohm
±3.5 ohm
±3.5 ohm
±4.5 ohm
±4.5 ohm
±5.5 ohm
Reserve
Reserve
FUEL BARS OHMS TOLERANCE
